Project eta
AerospaceCAD
Aerospace Tier I Supplier – Design
Need:
To setup an offshore CAD Team to support Structural Designing requirements for Primary and Secondary Structures, NMG creations, Conceptual, Preliminary Design and Final Design, Surface /Solid Modeling of parts, sub-assemblies and assemblies with engineering drawings at SOLIZE Bangalore, India
Outcome:
Primary Structure
- SOLIZE Design team supported Customer’s Design department by performing Design of Fixed and Tilt Wings and Flap & Flaperon involving composite material lay-up, design of Wing to Fuselage attachment, and Torque tube actuator attachments
- SOLIZE Design team was involved in conceptual design and preliminary design of Spars, Ribs, Skins, and Brackets; also involved in design phases to freeze the final configuration
- SOLIZE Design team provided support for Fuselage design, viz.
- Design and modeling of Bulkheads at different Aircraft stations
- Design, modeling and detailing of Longerons, Stringers
- Design, modeling and detailing of Canopy Assembly and its related sub-parts
Interior Design
- SOLIZE has experience in the design of galleys:
- Galley design based on fixed and adaptable zones with forward and aft facing
- Detailed design, 3D modeling, and assembling
- Creation of 2D manufacturing drawings
- Design of Flight Deck based on surface design and 3D modeling
Tool used:
CATIA V5
